• • • • • Introduction This document provides a sample configuration of stub multicast routing on the ASA and how to test using third party tools. Prerequisites Requirements The document assumes the reader have full understanding on how multicast traffic flows and multicast terminologies. As a summary, stub multicast routing on the ASA firewall is setting up the appliance to act as an IGMP proxy agent. The ASA will forward the IGMP messages (join and leave) received from the ingress interface (e.g. Inside) towards the egress interface (e.g.

In addition, the forwarded IGMP message source address will be modified to use the ASA engress ip address therefore not exposing the inside ip address to the outside. Stub multicast routing is useful when the network does not need to participate in PIM.

In order for the multicast stream to be routed, multicast-routing must still be enabled. However, both PIM and Stub multicast routing are not supported concurrently. As a result, you need to disable any PIM parameters configured on the ASA (e.g. Pim rp-address) to avoid conflict. There is no need to specifically disable pim on the interfaces. The sample configuration will simulate a multicast sender on the outside and receiver on the inside.

Components Used Following components are used on this setup • ASA 5505 running 8.4.1 • iperf traffic generator Note: iperf is a freeware software that can be downloaded from the internet. Its available both on windows and unix/linux machines. Configure This section describes the information you need to configure the features described in this document. Enable multicast routing asa(config)# multicast-routing Step 2.

Remove any PIM specific configuration on the ASA if there's any asa(config)# no pim rp-address x.x.x.x Step 3. Enable igmp forward asa(config)# interface vlan1 asa(config-if)# igmp forward interface outside Step 4. Since the multicast stream will come from the outside, access-list is required asa(config)# access-list outside_in permit udp any host 239.1.1.1 asa(config)# access-group outside_in in interface outside Network Diagram This document uses this network topology: sender---(outside)ASA5505(inside)----receiver sender: 171.69.89.21 recevier: 192.168.16.203 multicast group: 239.1.1.1 Configurations This document uses these configurations (stripped unnecessary lines): ASA Version 8.4(1)! Hostname asa domain-name cisco.com multicast-routing names! Interface Vlan1 nameif inside security-level 100 ip address 192.168.16.1 255.255.255.0 igmp forward interface outside!

Interface Vlan2 nameif outside security-level 0 ip address dhcp setroute! Interface Ethernet0/0 switchport access vlan 2!

Interface Ethernet0/1! Interface Ethernet0/2!

Interface Ethernet0/3! Interface Ethernet0/4! Interface Ethernet0/5!

Interface Ethernet0/6! Interface Ethernet0/7! Object network obj_any subnet 192.168.16.0 255.255.255.0! Access-list outside_in extended permit udp any host 239.1.1.1 access-group outside_in in interface outside! Object network obj_any nat (inside,outside) dynamic interface! Policy-map type inspect dns preset_dns_map parameters message-length maximum 512 policy-map global_policy class inspection_default inspect dns preset_dns_map inspect ftp inspect h323 h225 inspect h323 ras inspect rsh inspect rtsp inspect esmtp inspect sqlnet inspect skinny inspect sunrpc inspect xdmcp inspect sip inspect netbios inspect tftp inspect icmp service-policy global_policy global!

Verify Use this section to confirm that your configuration works properly. Install iperf both on the sender and receiver machines Step 2. Prepare the receiver to request for the multicast traffic on the preferred multicast group On the receiver, execute the following iperf command. Iperf -s -u -B 239.1.1.1 -i 1 s – server u – udp B – binding i - interval Note: Use the iperf documentation to learn more about the options used above. The above iperf command will send an IGMP join to 239.1.1.1.

To verify the ASA receives this, the “show igmp groups” can be used. Asa(config)# sh igmp groups IGMP Connected Group Membership Group Address Interface Uptime Expires Last Reporter 239.1.1.1 inside 00:00:02 00:04:18 192.168.16.203 In addition, the ASA will populate a shared tree (*,G) entry on the mroute table. Asa(config)# sh mroute 239.1.1.1 Multicast Routing Table Flags: D - Dense, S - Sparse, B - Bidir Group, s - SSM Group, C - Connected, L - Local, I - Received Source Specific Host Report, P - Pruned, R - RP-bit set, F - Register flag, T - SPT-bit set, J - Join SPT Timers: Uptime/Expires Interface state: Interface, State (*, 239.1.1.1), 00:00:52/never, RP 0.0.0.0, flags: DC Incoming interface: Null RPF nbr: 0.0.0.0 Immediate Outgoing interface list: inside, Forward, 00:00:52/never Step 3. Start sending multicast stream. On the sender, execute the following iperf -c 239.1.1.1 -u -T 1 -t 3 -i 1 c – client u – UDP T – ttl t - time i - interval The ASA mroute table will have a source tree (S,G) entry for the sender upon receiving the traffic stream.
